Alcoa Camloc - Stud Assembly, Turnlock Fastener | 26S8-5

The Camloc 26S8-5 Stud is a phillips recess, fillister head fastener stud from the Calmoc 2600 series. Has a length of .880" and a total grip thickness of .150"-.179". These light-duty Camloc studs are rated for 200 pounds working strength (ultimate tensile strength 300 pounds). Made from steel with zinc plating.

Features

• Product Type: Stud
• Fastener Series: 2600
• Stud Size: 5
• Stud Type: Low Profile
• Head Type: Phillips
• Head Shape: Fillister
• Body Material: Zinc Plated Steel
• Total Stud Length: .880in [22.35mm]
• Total Material Thickness
• w/ fixed receptacle: .150-.179in [3.81-4.54mm]
• w/ adjustable receptacle: .130-.490in [3.30-12.44mm]
• Working Strength: 200 lbs
• Ultimate Tensile Strength: 300 lbs
